Product Summary
The STV5730-1 IC is intended to be used in VCR, Satellitereceiver and PAY-TV systemsfor CVBS or R/G/B text/graphics insertion.
Parametrics
Absolute maximum ratings: (1)Digital Supply Voltage, DVDD: 7V; (2)Analog Supply Voltage, AVDD: 7V; (3)Junction Temperature, Tj: 150℃.
Features
Features: (1)a character generator with ASCII RAM and character ROM reference; (2)line lockedpll; (3)video timing generator input CVBS clamp and sync extrac TOR; (4)verticalsyncseparator; (5)input CVBS sync re-insertion; (6)input CVBS presence detector; (7)pal/ntscchroma encoder dedicated pins for luma and chroma; (8)external filtering gain on cvbs output for either 0dB; (9)or 6dB capability multistandard translucent mixed mode; (10)opaquemixed mode; (11)normal full page mode; (12)video full page mode; (13)suitable for S-VHS three different markers can be; (14)generated simultaneously three wire serial interface for microprocessor control.
Diagrams
 |
